10-Gigabit/Multi-Gigabit Smart Managed Plus

$2,400.00

10-Gigabit/Multi-Gigabit Smart Managed Plus

$2,400.00

Category: .
100M/1G/2.5G/5G/10G RJ-45 copper ports
  • 2
10M/100M/1G Copper ports
  • 8
Datasheet (PDF)
Form Factor
  • Desktop/Wall-Mount/Rackmount
Packet buffer memory
  • 128KB
Bandwidth
  • 56Gbps
MAC Address database size
  • 16K
VLAN (# supported)
  • 64
Number of LAGs & number of members
  • 5 LAGs with max 9 members in each LAG
Supported multicast groups
  • 128
Max number of source ports allowed (many to one port mirroring)
  • 9
Bandwidth
  • 56Gbps
Fan(s)
  • 0 ( Fanless)
IEEE 802.3az (Energy Efficient Ethernet)
  • Yes
Max power consumption (Watts)
  • 13.2W
LEDs
  • Power, Speed, Link/Activity
Acoustic noise level @ 25° C (dBA)
  • 0
Operating temperature
  • 0° to 40° C
Electromagnetic compliance (A or B)
  • B
Dimensions (W x D x H)
  • 236 x 102 x 27 mm (9.29 x 4.02 x 1.06 in)
Weight
  • 0.75 kg (1.63 lbs)
